Metallic Enhancers High Performance Cast Vinyl Series Metallic Enhancer film 6300 is a premium 2.5-mil (Crystal) and 3.0-mil (Silver and Multicolor metallic flake) cadmium-free clear cast vinyl with high gloss and a high concentration of light refracting additives for a glistening appearance on the surface of your substrate or to use as an overlaminating film to greatly enhance your high quality graphics. These MACtac films are designed for high profile applications over flat to slightly curved surfaces. The products are coated with a high-performance permanent, clear solvent acrylic adhesive protected with 78# bleached white kraft liner for good stability and layflat. These films are outstanding choices for creating unique effects in fleet marking, container decals, marine, logos, automotive, equipment identification, signs, etc.
You Must be Logged in to Add the Item to your Cart.
Description
PRODUCT: 6300 Metallic Enhancers High Performance Cast Vinyl Series
PRODUCT DESCRIPTION:
Metallic Enhancer film 6300 is a premium 2.5-mil (Crystal) and 3.0-mil (Silver and Multicolor metallic flake) cadmium-free clear cast vinyl with high gloss and a high concentration of light refracting additives for a glistening appearance on the surface of your substrate or to use as an overlaminating film to greatly enhance your high quality graphics.
These MACtac films are designed for high profile applications over flat to slightly curved surfaces. The products are coated with a high-performance permanent, clear solvent acrylic adhesive protected with 78# bleached white kraft liner for good stability and layflat. These films are outstanding choices for creating unique effects in fleet marking, container decals, marine, logos, automotive, equipment identification, signs, etc.
TYPICAL VALUES*
PHYSICAL PROPERTIES: TEST METHOD
Thickness, inches (μm) ASTM D-645
Film plus adhesive
Crystal 0.0037 (94
Silver and Prism 0.0042 (107)
Peel Adhesion, lb. /in. (N/25 mm) ASTM D-903
180° on Stainless Steel - 20 min. 2.8 (12.7)
- 24hrs. 4.0 (17.8)
Face Material Data, 68°F (20°C)
Tensile strength lb. /in. (N/m) >7.5 (1300) DIN 53455
Elongation % >120%
Dimensional Stability (shrinkage), % 10” x10” Sample
48 hours @ 158°F (70°C) bonded to aluminum mounted on aluminum
<0.1
Temperature Ranges
Application: 40° to 104°F (5° to 40°C)
End Use: -50° to 225°F (-45° to 107°C)
DURABILITY:
This product is good for 5-year in outdoor durability. This use-life estimate is based upon accelerated age studies based on vertical applications under “normal” temperate climates. Please note that exposure to severe temperatures, ultra-violet light and also tropical, sub-tropical or desert regions will cause more rapid deterioration. This also applies to polluted areas, high altitude and south facing exposure.
SHELF LIFE:
Two years when stored between at 60- 80°F (15 - 25°C) and 50% relative humidity or less.
IMPORTANT NOTICE: The information given and the recommendations made herein are based on our research and are believed to be accurate, but no guarantee of their accuracy or completeness is made. In every case, user shall determine before using any product in full scale production, or in any way,
whether such product is suitable for user’s intended use for their particular purpose under their own operating conditions. User assumes all risk and liability
whatsoever in connection with their use of any product. The products discussed herein are sold without any warranty as to merchantability or fitness for a particular purpose, or any other warranty, express or implied. No representative of ours has any authority to waive or change the foregoing provisions, and
no statement or recommendation not contained herein shall have any force of effect unless in an agreement signed by the officers of seller andmanufacturer. Nothing contained herein shall be construed to imply the nonexistence of any relevant patents or to constitute a permission, inducement or
recommendation to practice any invention covered by any patent without authority from the owner of the patent. The following is made in lieu of allwarranties, express or implied: Seller’s and manufacturer’s only obligation shall be to replace or credit such quantity of the product proved to be defective
at its discretion.
TM Trademark of Morgan Adhesives Company.
® Registered Trademark of Morgan Adhesives Company.
www.MACtac.com
CHEMICAL RESISTANCE:
A sample is prepared in the same manner as for the Chemical Resistance Test and is immersed in the test fluid followed by drying at each stage.
Test Fluid Observation
Gasoline (30min) No Effect
Distilled Water (24 hrs) No Effect
SAE 20 Motor Oil (1 hr) No Effect
10% HCL (10min) No Effect
10% NH4OH (10 min) No Effect
APPLICATION:
Used as cut vinyl - Application of 6300 when used as cut-vinyl is made easier if MACtac pre-spacing tape is used, or can be applied as an overlaminating film with a standard laminator. Where exposures to chemical and solvent spills are likely to occur, edge sealing of decals with a varnish or
clear coat will prevent edge lift. Correct varnishing of decals gives greater protection and longer enduser life against any prolonged effect of weathering, abrasion and other erosive effects such as frequent cleaning.
Used as an Overlaminate for Vehicle Wraps - Because this is a much thicker overlaminate MACtac offers a limited warranty on flat to slightly curved surfaces. There is no warranty for Enhancers on motor vehicle wraps, over rivets and corrugations, through complex surfaces or for marine graphics.
1) The user is responsible for determining the product’s suitability, including adhesion and if needed, removal characteristics when used in applications other than listed specifically in this Performance Guide.
2) If there are any questions about applications, please contact your MACtac sales
representative to discuss your requirements for recommendations.
3) If this is a printed Performance Guide it is an uncontrolled document. Please check the MACtac website for the latest, most up-to-date version.
* Values given are typical and are not necessarily for use in specification.
CALL 1-888-477-8465 for additional product information
