IMAGin® WN628 WallNOODLE is a 6.0-mil matte white, semi rigid calendered PVC film designed for UV screen, solvent-based ink jet and off-set printing. The product is coated on one side with a removable and repositionable acrylic pressure sensitive adhesive and supplied with a 90# P.E. coated kraft liner. WN628 is designed for short term (6 months to one year) indoor wall graphics on smooth, flat surfaces.
You Must be Logged in to Add the Item to your Cart.
Description
PRODUCT: IMAGin® WN628 WallNOODLE is a 6.0-mil matte white, semi rigid calendered PVC film designed for UV screen, solvent-based ink jet and off-set printing. The product is coated on one side with a removable and repositionable acrylic pressure sensitive adhesive and supplied with a 90# P.E. coated kraft liner. WN628 is designed for short term (6 months to one year) indoor wall graphics on smooth, flat surfaces.
PHYSICAL PROPERTIES: TYPICAL VALUES* TEST METHOD
Thickness, inches (µm) ASTM D-645
Film plus adhesive 0.007 (112)
Peel Adhesion, lb. /in. (N/25mm) ASTM D-903
180° on Stainless Steel - 24 hr. 0.85 (3.72)
Quick Tack on SS, lb. /in² (N/25mm) 0.80 (3.50) MACtac CTM-25
Dimensional Stability, (%) MACtac CTM-21
48 hours @ 158°F (70°C) (Method D)
MD 0.40 10” x 10” Sample
CD 0.20 bonded to aluminum.
Temperature Ranges,
Minimum Application: 50°F (+10°C)
End Use: -20°F to 158°F (-6°C to 70°C)
Surface Burning Characteristics ASTM E84-01 or
Flame Spread 15 ANSI/NFPA 255 or
Smoke Density 50 UCB 8-1
Meets: ANSI Class A
NFPA Class A
UCB Class 1
INTENDED FOR: Wide format, screen, eco-solvent, solvent-based, latex, UV-cured inkjet and off-set printing
using UV inks or plastic/oxidizing inks. To achieve the best possible print quality, please make sure that the correct
ICC profiles or printer settings are used. Profiles can be downloaded from www.mactac.com. Printer and heater
settings and ICC profiles can also be downloaded from some O.E.M. or software manufacturer’s websites.
The ICC profiles are provided solely as a customer resource. Print environments, the individual nature of printing
systems, inks and software can significantly affect output. It is the customer’s responsibility to determine the
suitability of any profile for use in their specific print environment.
