Fedrigoni 12 YR Cast Gloss Lam

    Fedrigoni 12 YR Cast Gloss Laminate

    Advanced Wrapping Film for Everyone



    This 1.2 mil Clear Premium Cast Wrapping Film is specially produced using the latest ingredients in the cast PVC formulation for lamination applications in conjunction with vehicle wrapping films. It is specifically designed for vehicles (cars, fleet, trucks, trailers, boats, trains) wrapping applications. This Premium Cast film is the ideal solution for customizing or branding any type of vehicle or commercial fleet. Easily conformable on any 3D surface.

Available Options

You Must be Logged in to Add the Item to your Cart.

Click Here to Login

Click Here to Register for a new Account

Description

    Fedrigoni 12 YR Cast Gloss Laminate

    Key Features



    Pre-Stretch



    The premium Cast Film is pre-stretched at the factory. This construction builds in surface tension, allowing installers to use a tension-free technique that utilizes heat to make the product shrink into and conform to surfaces by itself. This allows for a faster workflow with significantly less effort. Simply apply heat and allow it to cool. Then apply normally for bubble-free application to any 3D surface.



    Superior Flexibility and Conformability



    The high quality of the PVC guarantees optimal application on the most complex surfaces (rivets, concave and convex surfaces) that require a highly conformable and adaptable material for the best finish, especially when paired with Ri-Jet C50 Ultimate Slide and Tack cast print vinyl. This ensures high dimensional stability over the life of the application.



    Benefits of Lamination

    Over-lamination is recommended to prevent abrasion, extend colorfastness, and also offer easier handling and installing.



    Construction and Specs

    Face Film

    • Face Film: Clear CAST Vinyl Film
    • Gauge: (ISO 2286-3) 1.18 mil (30 micron) nominal

    Adhesive



    • Type: Permanent clear permanent solvent-based acrylic pressure-sensitive adhesive
    • Minimum application temperature: +10C
    • Service temperature: -40C to +90C

    Release Liner



    • Weight: 135 gsm nominal
    • Type: Clay-coated kraft paper

    Finishes



    • Gloss
    • Matte available upon request

    Roll Size

    • 54" x 150'
    • 60" x 150' available upon request (custom order)

    Durability

    • Shelf Life: 2 years from date of manufacture when stored in proper conditions 73*F and 50% RH.
    • External weathering: Up to 6 years (zone 1). This refers to the unprinted vinyl.
    • This product is REACH and RoHS compliant.



    Application

    • Allow a minimum of 24-48 hours for ink to dry before application of the overlaminate. Depending on the print and drying conditions this can often be in excess of 48 hours. Retained solvents will reduce adhesion levels.
    • Successful vehicle wrap application requires the necessary techniques.
    • The recommended printed vinyl to pair with Ri-Lam C30 Ultimate Laminate is Ri-Jet C50 Ultimate Slide and Tack.
    • Do not overstretch as this will cause the application to fail.
    • The vinyl needs to be heated at 35-40*C before being conformed to 3D areas.
    • The user should determine the suitability of the substrate.
