Mactac’s 5798MBF is a 3.1-mil translucent matt dusted polymeric PVC film designed for solvent-based ink jet printing. The product is coated on one side with a micro-structured ,repositionable, permanent, clear acrylic pressure sensitive adhesive and is supplied with 80# Polycoated, layflat liner. The micro-structured adhesive allows for the increased speed of dry application on windows with no air bubbles or wrinkling. It also eliminates the messy clean up of wet-application fluids. JT 5796BF is designed for indoor and outdoor window graphics.
You Must be Logged in to Add the Item to your Cart.
Description
Self-adhesive Digital Imaging Media for wide-format solvent-based & UV inkjet Printing IMAGin JT 5798M BF issue 5 JS 10/2008 Page 1 / 2
JT 5798 MBF Technical Data Sheet
PRODUCT DESCRIPTION
FACE MATERIAL : 5 year polymeric calendered vinyl80 µ translucent matt dusted polymeric PVC film
ADHESIVE : Micro-structured repositionable permanent acrylic.
LINER : PE coat liner 130 gsqm backprinted BF series.
TYPICAL USES
Long term outdoor & indoor decoration of windows (restaurants, museums, showrooms, shopping malls,
etc).
Product benefits : dry application at it’s best!
A patented performance feature enabling the Applicator of the printed decal to apply much faster and to limit the risks of
wrinkles and entrapped air bubbles generally associated with the application of large format decals.
BF series therefore save time by increasing productivity during the application job. The micro-structured repositionable
adhesive system allows the installer to remove and re-apply the decals during the job. It is possible to press out small
entrapped air bubbles with ease!
As a result : A great looking job!
PRINTING
Especially designed for solvent based & UV inkjet printing on wide-format printing equipment.
To achieve the best possible print quality, please make sure that the correct ICC profiles or printer settings are used.
Profiles can be obtained from our Subsidiaries, Distributors or can be downloaded from www.mactac-europe.com
Printer & Heater settings and ICC profiles are also downloadable from some of the OEM’s web sites.
Important notice : It is CRITICAL that any digital prints are TOTALLY DRY before application. While this is important for
all films in the JT 5000 range it is even more important for the special tack system of JT 5798M BF.
If the film is not dried sufficiently the vinyl and adhesive will still be full of solvents which change the properties and
consequently the behaviour of the film. The customer will therefore not benefit from the bubble free effect enough to reduce
application time. It can also cause adhesive residue to be left behind and lack of repositionnability.
This is also important when laminating the printed decal.
PHYSICAL PROPERTIES OF THE UNPRINTED FILM
Average values Test method
Adhesive Data, 23°C
Quick Tack on glass
Peel 24 hours on glass
23 ± 3 N/25 mm
15 ± 3 N/25 mm
FTM 9
FTM 1
Dimensional stability
shrinkage : 48 hours at 70°C
(applied on aluminium) Max 0.5 mm FTM 14
Flammability Self-extinguishing applied on Alu panels
Temperature ranges
Minimum application temperature :
Service temperature range : + 10°C - 20°C to + 70°C
IMAGin JT 5798M BF issue 5 JS 10/2008 Page 2 / 2
SHELF LIFE
2 years when stored at 15 to 25°C and ± 50 % relative humidity (in the original packaging).
DURABILITY
The outdoor durability of the unprinted film is 5 years.
RECOMMENDATIONS
Always test the combination of JT 5000 products, inks and laminating films prior to commercial use.
Printing conditions
A conditioned pressroom, ± 23°C and 50 % R.H.
Transportation conditions
To allow easy transportation, IMAGin JT series can be rolled up, with the image on the outside, with a minimum
diameter of 15 cm (for example on a 6 inches core).
Make sure that the print is perfectly dry before rolling it over. To avoid exposing the print to any liquid aggressions,
prints should be protected by a plastic bag. During the transport or storage of the prints, avoid exposing them to
extreme temperature and humidity variations.
GENERAL REMARK : factors affecting adhesion
To ensure application suitability - always test the proposed construction under actual application and end-use conditions before
going into full production.
The following factors will adversely affect adhesion of a pressure-sensitive adhesive:
* Dusty, dirty, oily or oxidized surfaces
* Mould release agents on blow-moulded plastic surfaces
* Low surface energy substrates, such as: polyethylene, polypropylene...
* Application below the minimum application temperature or use outside of the recommended service temperature ranges.
IMPORTANT NOTICE
All MACtac products are subject to careful quality control throughout the manufacturing process and are warranted to be of
merchantable quality and free from manufacturing defects.
Published information concerning MACtac products is based upon research which the Company believes to be reliable
although such information does not constitute a warranty.
Because of the variety of uses of MACtac products and the continuing development of new applications, the purchaser should
carefully consider the suitability and performance of the product for each intended use, and the purchaser shall assume all risks
regarding such use. The seller shall not be liable for damages in excess of the purchase price of the product nor for incidental
or consequential damages.
All specifications are subject to change without prior notice.
